    DIY Wig Storage Cart: Solve All Wig Chaos for Just $170

    Tired of wigs tangled, doors sagging, or shapes ruined? This guide shows you how to build a mobile wig storage cart for under $170 that keeps wigs perfectly shaped, organized, and ready to use. Includes 16 detailed real photos (materials, assembly, finished cart angles) — beginner-friendly and perfect for long-term wig care!

    Wig Storage

    Storing a wig correctly will keep the right shape.

    You can use theses on the door but adding to much weight on a door will cause issues on the hinges and may cause your door to sag and to not close well in the future. I put them on Carts Instead.

    Wig hanger hooks Figure 1: Wig hanger hooks.

    The Traditional Door Method vs The Cart Method

    Wigs hanging on a door Figure 2: Traditional storage method - wigs hanging on a door.
    Another view of the storage cart Figure 3: The cart method - a mobile and organized alternative.

    I made theses because the Wigs actually started messing with my door henges and I wanted to stop that so I made these, the total cost for the cart is around 90 USD + the wig hanger sets (with that it’s around 170 Total) It also depends on the amount of brackets you want.

    Parts you need

    1. 4x Caster wheel
    2. 1x 2x4 Half inch plywood you can get a full sheet to save money in the long run.
    3. 3x 3” by 2” pine wood. (reality its 2½” by 1½” USA)
    4. 4x 4” by 1” select pine boards (reality its 3½ by ¾ USA)
    5. 1LB 3 ½ long wood screws
    6. 1x 1 ¼ inch wood screws
    7. 16x ¼ thick Bolts and nuts or the bolt fit the caster wheel
    8. 12x L brackets
    Standard swivel caster wheel product Figure 4: Product example: A standard 3-inch light-duty swivel caster wheel.
    Swivel caster wheel with brake product Figure 5: Product example: A 3-inch swivel caster wheel with a locking brake.
    Select pine board product Figure 6: Material example: 1"x4"x8' Premium Kiln-Dried Select Pine Board.
    #8 wood deck screws product Figure 7: Hardware example: #8 x 1-1/4 inch Tan Star Flat-Head Wood Deck Screws.
    #10 wood deck screws product Figure 8: Hardware example: #10 x 3-1/2 inch Tan Star Flat-Head Wood Deck Screws.
    Galvanized angle bracket product Figure 9: Product example: 2 in.x 1-1/2 in.x 1-3/8 in. ZMAX Galvanized Angle (L bracket).

    When getting the plywood, you can get a full 4/8 sheet but that will be a lot of wood. You will save money in the long run cutting it yourself but some people do not have the space.

    Cart assembly sketch Figure 10: Assembly sketch: shows wheel placement and joinery details for the frame.

    I use select pine to not have it be bulky and also be lighter. You’re not making something to carry 1000 LB (450 KG or so) of stuff.

    Close-up of select pine wood Figure 11: Material close-up: The select pine wood.
    Caster wheel bolted to wood Figure 12: Build detail: Caster wheel securely attached using a bolt and nut.

    This is more so show what you can do while not spending to much. I bolted in the wheels with nuts on the other side. You can also use “lag” screws as well.

    I hollowed out holes for the bolts and nut and washers to give a lot more strength. I can also use this cart to move heavier stuff in the future so I future proof these things.

    Counterbored hole in wood Figure 13: Build detail: A counterbored hole creates a flush surface for the bolt head, resulting in a stronger joint.

    You can use theses craft foam heads to hold more detailed and valuable wigs that you want to keep preserved.

    Craft foam wig heads Figure 14: Accessory: Craft foam heads are ideal for preserving the shape of delicate or styled wigs.

    I keep my wigs largely separated from very long and more traditional lengths.

    Long wigs stored on cart Figure 15: Organization: One side of the cart dedicated to shorter, traditional-length wigs.
    Shorter wigs stored on cart Figure 16: Organization: The other side dedicated to storing long wigs.

    The bottom is handy for wig parts and Wig tools.
